This is because the inductor responds to changes in current by inducing its own voltage to counter the change in current, and this voltage adds to the source voltage while the switch is open. If a diode-and-capacitor combination is placed in parallel to the switch, the peak voltage can be stored in the capacitor, and the capacitor can be used as a DC source with an output voltage greater than the DC voltage driving the circuit.

This boost converter acts like a step-up transformer for DC signals. A buck—boost converter works in a similar manner, but yields an output voltage which is opposite in polarity to the input voltage. Other buck circuits exist to boost the average output current with a reduction of voltage. In a SMPS, the output current flow depends on the input power signal, the storage elements and circuit topologies used, and also on the pattern used e. The spectral density of these switching waveforms has energy concentrated at relatively high frequencies. As such, switching transients and ripple introduced onto the output waveforms can be filtered with a small LC filter.

The main advantage of the switching power supply is greater efficiency than linear regulators because the switching transistor dissipates little power when acting as a switch.

Partner Login

Other advantages include smaller size, lower noise, and lighter weight from the elimination of heavy line-frequency transformers, and comparable heat generation. Standby power loss is often much less than transformers. The transformer in a switching power supply is also smaller than a traditional line frequency 50Hz or 60Hz depending on region transformer, and therefore requires smaller amounts of expensive raw materials, like copper. Disadvantages include greater complexity, the generation of high-amplitude, high-frequency energy that the low-pass filter must block to avoid electromagnetic interference EMI , a ripple voltage at the switching frequency and the harmonic frequencies thereof.

Non- power-factor-corrected SMPSs also cause harmonic distortion. There are two main types of regulated power supplies available: SMPS and linear. The following table compares linear regulated and unregulated AC-to-DC supplies with switching regulators in general:. This is called rectification. In some power supplies mostly computer ATX power supplies , the rectifier circuit can be configured as a voltage doubler by the addition of a switch operated either manually or automatically.

The rectifier produces an unregulated DC voltage which is then sent to a large filter capacitor. The current drawn from the mains supply by this rectifier circuit occurs in short pulses around the AC voltage peaks. These pulses have significant high frequency energy which reduces the power factor.

To correct for this, many newer SMPS will use a special PFC circuit to make the input current follow the sinusoidal shape of the AC input voltage, correcting the power factor. This type of use may be harmful to the rectifier stage, however, as it will only use half of diodes in the rectifier for the full load. This could possibly result in overheating of these components, causing them to fail prematurely. The diodes in this type of power supply will handle the DC current just fine because they are rated to handle double the nominal input current when operated in the V mode, due to the operation of the voltage doubler.

This is because the doubler, when in operation, uses only half of the bridge rectifier and runs twice as much current through it. The inverter stage converts DC, whether directly from the input or from the rectifier stage described above, to AC by running it through a power oscillator, whose output transformer is very small with few windings at a frequency of tens or hundreds of kilohertz.

If the output is required to be isolated from the input, as is usually the case in mains power supplies, the inverted AC is used to drive the primary winding of a high-frequency transformer. This converts the voltage up or down to the required output level on its secondary winding. The output transformer in the block diagram serves this purpose.

If a DC output is required, the AC output from the transformer is rectified. For output voltages above ten volts or so, ordinary silicon diodes are commonly used. For lower voltages, Schottky diodes are commonly used as the rectifier elements; they have the advantages of faster recovery times than silicon diodes allowing low-loss operation at higher frequencies and a lower voltage drop when conducting.

For even lower output voltages, MOSFETs may be used as synchronous rectifiers ; compared to Schottky diodes, these have even lower conducting state voltage drops. The rectified output is then smoothed by a filter consisting of inductors and capacitors. For higher switching frequencies, components with lower capacitance and inductance are needed. Simpler, non-isolated power supplies contain an inductor instead of a transformer. This type includes boost converters , buck converters , and the buck—boost converters. These belong to the simplest class of single input, single output converters which use one inductor and one active switch.

Protection of Systems from Surges and Transients

The buck converter reduces the input voltage in direct proportion to the ratio of conductive time to the total switching period, called the duty cycle. A feedback control loop is employed to regulate the output voltage by varying the duty cycle to compensate for variations in input voltage. The output voltage of a boost converter is always greater than the input voltage and the buck—boost output voltage is inverted but can be greater than, equal to, or less than the magnitude of its input voltage.

There are many variations and extensions to this class of converters but these three form the basis of almost all isolated and non-isolated DC to DC converters. Other types of SMPSs use a capacitor — diode voltage multiplier instead of inductors and transformers. These are mostly used for generating high voltages at low currents Cockcroft-Walton generator. The low voltage variant is called charge pump. A feedback circuit monitors the output voltage and compares it with a reference voltage.

Depending on design and safety requirements, the controller may contain an isolation mechanism such as an opto-coupler to isolate it from the DC output. Switching supplies in computers, TVs and VCRs have these opto-couplers to tightly control the output voltage. Open-loop regulators do not have a feedback circuit.

DC power supply specialist

Instead, they rely on feeding a constant voltage to the input of the transformer or inductor, and assume that the output will be correct. Regulated designs compensate for the impedance of the transformer or coil. Monopolar designs also compensate for the magnetic hysteresis of the core. The feedback circuit needs power to run before it can generate power, so an additional non-switching power-supply for stand-by is added.

Any switched-mode power supply that gets its power from an AC power line called an "off-line" converter [33] requires a transformer for galvanic isolation. Some DC-to-DC converters may also include a transformer, although isolation may not be critical in these cases. SMPS transformers run at high frequency. There are additional design tradeoffs.

The terminal voltage of a transformer is proportional to the product of the core area, magnetic flux, and frequency. By using a much higher frequency, the core area and so the mass of the core can be greatly reduced. However, core losses increase at higher frequencies. Cores generally use ferrite material which has a low loss at the high frequencies and high flux densities used. Also, more energy is lost during transitions of the switching semiconductor at higher frequencies. Furthermore, more attention to the physical layout of the circuit board is required as parasitics become more significant, and the amount of electromagnetic interference will be more pronounced.

Professional

For these frequencies, the skin effect is only significant when the conductors are large, more than 0. Switching power supplies must pay more attention to the skin effect because it is a source of power loss. The effective resistance of conductors increases, because current concentrates near the surface of the conductor and the inner portion carries less current than at low frequencies.

The skin effect is exacerbated by the harmonics present in the high speed pulse width modulation PWM switching waveforms. The appropriate skin depth is not just the depth at the fundamental, but also the skin depths at the harmonics. In addition to the skin effect, there is also a proximity effect , which is another source of power loss. Simple off-line switched mode power supplies incorporate a simple full-wave rectifier connected to a large energy storing capacitor.

Such SMPSs draw current from the AC line in short pulses when the mains instantaneous voltage exceeds the voltage across this capacitor. During the remaining portion of the AC cycle the capacitor provides energy to the power supply. As a result, the input current of such basic switched mode power supplies has high harmonic content and relatively low power factor.
